AC115V 30W Sound System Controller Audio Power Sequencer ROHS

AC115V 30W Sound System Controller Audio Power Sequencer ROHS
AC115V 30W Sound System Controller Audio Power Sequencer ROHS AC115V 30W Sound System Controller Audio Power Sequencer ROHS AC115V 30W Sound System Controller Audio Power Sequencer ROHS

Large Image :  AC115V 30W Sound System Controller Audio Power Sequencer ROHS

Product Details:
Place of Origin: Guangzhou China
Brand Name: FTD
Certification: CE，ROHS
Model Number: FTD-16PS
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: $138~200
Packaging Details: carton
Delivery Time: 7 work days
Payment Terms: T/T
Supply Ability: 1000 Piece/Pieces per Month
Contact Now

AC115V 30W Sound System Controller Audio Power Sequencer ROHS

Description
Description: 16 Channel Power Sequencer Interval Time: 1.5 Second
Dimension: 430(W)*260(D)*88(H)mm Power Consumption: 30W
Indicators: 16 Channel Working Status On Front Panel Weight: 5.6kg
High Light:

audio power sequencer ROHS

,

AC115V sound system controller

,

ac power sequencer 30W

Sound System Power Controller 16 Channel Power Sequencer





Features:

1.19" rack mount power sequencer for low voltage system and PA sound system 2.16 channel power sequencer to manual or auto power control the amplifier 3.By using this programmable power sequencer to power on/off the amplifier in sequence to avoid high current to damage the amplifier or the power supply system 4.The interval time is 1.5 seconds between 2 channel actions 5.With universal power socket compatible for European, British and Chinese power plug 6.Each channel with working status on front panel for monitor use 7.Maximum loading capacity is 8,000 watts for total 16 channels 8.Each channel maximum output current is 10A 9.Total 16 channel maximum output current is 30A 10.With remote power control terminal open circuit to power on and short circuit to power off this unit 11.AC 115V or 230W power operation, 50-60Hz
AC115V 30W Sound System Controller Audio Power Sequencer ROHS 0AC115V 30W Sound System Controller Audio Power Sequencer ROHS 1

Specification:
Model
FTD-16PS
Description
16 Channel Power Sequencer
Power Consumption
30W
Total Output Current
30A, 8,000W
Each Channel Output Current
10A, 750W
Interval Time
1.5 second
Indicators
16 channel working status on front panel
Power Socket
Multi-functional socket European, British and Chinese power plug
Remote Power Control
Remote power control terminal open circuit to power on and short circuit to power off this unit
Dimension
430(W)×260(D)×88(H)mm
Weight
5.6kg
Warranty
3 years



Company Profile

Guangzhou FTD Audio Limited is a leading manufacturer of Public Address System and Conference System in China, We are focus on R&D and our Professional R&D team already 15 years′ experience on Audio field. FTD audio will offer the professional products and
service to each of partner and do a win win business with our partners!
Our main products are Public address system ,EVAC system, IP PA system ,conference system ,PA amplifier and PA speaker.These
system are all designed and produced by our engineer. We are accept OEM,ODM order.





FAQ
1. Are you manufacturer?
Yes, we are public address system manufacturer located in Guangzhou, China.
Welcome to visit our factory.

2. Is sample order available? Is free sample available?
Firstly, sample order is available. Secondly, for new clients, we will return the sample fee after big order placed.

3. What's your warranty period?
Our warranty period is 12 months for speaker.

4. What's your payment terms?
We accept Western Union and TT. 30% deposit in advance, balance 70% before shipment.

5. Where is your main market?
Customers are mainly from Europe, Middle East and South Asia.

6. How many days do you need to prepare for the goods?
It takes 30 working days for large order.
