FTD 8 Channel PA Power Amplifiers 8*400W 57V Power Amp PA

FTD 8 Channel PA Power Amplifiers 8*400W 57V Power Amp PA
FTD 8 Channel PA Power Amplifiers 8*400W 57V Power Amp PA

Large Image :  FTD 8 Channel PA Power Amplifiers 8*400W 57V Power Amp PA

Product Details:
Place of Origin: Guangzhou China
Brand Name: FTD
Certification: CE
Model Number: FDP-4800
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Price: $ 130~600
Packaging Details: carton
Delivery Time: 7 work days
Payment Terms: T/T
Supply Ability: 1000 Piece/Pieces per Month
Contact Now

FTD 8 Channel PA Power Amplifiers 8*400W 57V Power Amp PA

Description
The Body Material: Metal Max Output: 57V
Certification: CE Warranty: 3months-1year
Shell Material: Metal Color: Black
High Light:

Pa Power Amplifiers 8*400W

,

57V power amp pa

,

FTD pa power amplifier

8*400W Pa Power Amplifiers Professional Power Amplifier Black



Features:

Robust performance range eight channel class-D power amplifier. Ideal for club, bar, restaurant & worship building sound system. Switching power technology digital Class-D level power amplifier. Green technology amplifier by 85% efficiency of less power consumption. Higher power output, less heat generation and longer life span. With PWM special power circuit to ensure excellent cooling system. 19" universal rack mount type in 1U height. Support power output of 8×500 Watt in stereo mode. 8 signal input connections by balanced phone jack. Loudspeaker outputs are connected using Speakon. Complete protection include clip, high temp, overload and short circuit. With four fans for cooling down the internal temperature. Visual indicator of output level meter, bridge, power, protection and clip.

Description:

The FTD 8 channel class-d amplifier FDP-8400 is designed of switching power technology, whose advantages are without transformer for less heat generation and long life span. Moreover, higher efficiency of more than 85% could help to decrease the power electricity consumption by green environment protection. Special power circuit design of PWM to ensure the world first level natural cooling system with additional four fans. The eight channel class-D amplifier is of 19" rack mount design is suitable for universal permanent installation of any sound reinforcement system. The digital Class-D technology also bring the lighter amplifier of less rack space consumption into true, so it is very useful and cost-effective amplifier for installer and system contractor. The rated power output of this amplifier is 8×500W, so it is ideal for meeting room, small stadium, bar, theme park and train station indoor and outdoor sound system, capacity of maximum connection of eight professional sound low impedance loudspeakers.


Specification
Model
FDP-8400
Description
Eight Channel Class-D Amplifier



Technology
Class-D
RMS Power @ 8 Ohm Stereo
8×400 Watt
RMS Power @ 4 Ohm Stereo
8×750 Watt
RMS Power @ 2 Ohm Stereo
8×750 Watt
Max Output
57V
Input Sensitivity
1V
Max Input Level
26dBu
Gain
34dB
THD
<0.5%
Crosstalk
>75dB
Frequency Response
20Hz~20KHz
Input Impedance
10K
Damping Parameter
>1000 (8Ω,20HZ~200HZ)
S/N Ratio
>105dB (20HZ~20KHZ)
Power Consumption
550VA (1/8 Max Output @4Ω)
Power Consumption
1100VA (1/4 Max Output @4Ω)
Connector
Input by Combo female, link by XLR female.
Efficiency
>85%
Power Supply
AC 220-240V or 115V, 50~60Hz
Dimension
484(W)*430(D)*44(H)mm
Weight
10.9kg

Company Profile

Guangzhou FTD Audio Limited is a leading manufacturer of Public Address System and Conference System in China, We are focus on R&D and our Professional R&D team already 15 years′ experience on Audio field. FTD audio will offer the professional products and
service to each of partner and do a win win business with our partners!

Our main products are Public address system ,EVAC system,
IP PA system ,conference system ,PA amplifier and PA speaker.These system are all designed and produced by our engineer. We are accept OEM,ODM order.
