Product Details:
|
| Description: | Class-D Professional Power Amplifier | Dimension: | 484(W) *375(D) *44(H)mm, 1RU Height |
|---|---|---|---|
| Warranty: | 3years | Power Supply: | AC 220~240V, 50/60Hz |
| Efficiency: | >85% | Crosstalk: | >75dB |
| Weight: | 8.5kg |
Feature:
| Model | FDP-2600 |
| Description | Class-D Professional Power Amplifier |
| Amplifier Class | D-Class |
| Power Output RMS Stereo | 2×350W@ 8Ω 2×500W@ 4Ω 2×600W@ 2Ω |
| Efficiency | >85% |
| Frequency Response | 20Hz~20KHz (at±0.3dB) |
| IMD-SMPTE | <0.3% |
| THD @ 1kHz | <0.3%, 1dB below clip |
| Damping Factor @ 8Ω | >800 |
| Slew Rate | 50V/µs |
| Signal/Noise Ratio | >105dB |
| Input Sensitivity | 1V |
| Voltage Gain | 35dB |
| Input Impedance | 20KΩ (bal.), 10KΩ (unbal.) |
| Crosstalk | >75dB |
| Connector | Input by XLR male, link by XLR female, output by Speakon female. |
| Protection | Clip, high temp, overload and short circuit |
| Cooling | Temperature controlled fan |
| Power Supply | AC 220~240V, 50/60Hz |
| Dimension | 484(W) ×375(D) ×44(H)mm, 1RU height |
| Net Weight | 8.5kg |
FAQ:
1. Are you manufacturer?
Yes, we are public address system manufacturer located in Guangzhou, China.
Welcome to visit our factory.
2. Is sample order available? Is free sample available?
Firstly, sample order is available. Secondly, for new clients, we will return the sample fee after big order placed.
3. What's your warranty period?
Our warranty period is 12 months for speaker.
4. What's your payment terms?
We accept Western Union and TT. 30% deposit in advance, balance 70% before shipment.
5. Where is your main market?
Customers are mainly from Europe, Middle East and South Asia.
6. How many days do you need to prepare for the goods?
It takes 30 working days for large order.
