Product Details:
|
| Description: | Class-D Single Channel Power Amplifier | Rated Power Output: | 500W |
|---|---|---|---|
| Speaker Output: | 70V, 100V And 4-16ohms, 6 Zone Speaker Out 100V | Frequency Response: | 60-15kHz |
| THD: | <0.5% At 1kHz, 1/3 Rated Power | S/N Ratio: | Line:85 DB , MIC:>72 DB |
| Protection: | High Temp, Short Circuit, Overload Protection | Power Supply: | AC230V Or AC110V, 50-60Hz |
| Power Consumption: | 550W | Dimension: | 484(W)*366(D)*88(H)mm |
| Gross Weight: | 5.5kg | Warranty: | 5 Years |
Description:
The 6 Zone Mixer Amplifier with MP3&FM tuner, with rated power output from 60W, 120W,240W, 350W to 500W,
It is ideal for background music system.
It is all in one solution include pre amplifier and mixer power amplifier into one 19" 2U height unit, which is economy of high reliable performance.
Various inputs includes phone jack front panel) and Mic/Line input 2-3 (6.3mm phone jack rear panel), two aux inputs (RCA rear panel).
One RCA line output for external mixer or amplifier.
Mic1 override other sources input and with mute level control amplifier is design with complete protection of overload, short circuit and high temp to avoid any damage.
Suitable for applications in bank, mosque, school theme centers and shopping center
Features:
Public address (PA) mixer amplifier.6 zone mixer power amplifier.19" rack mount amplifier of 2U height.Built-in MP3 player by USB & SD and FM tuner.Rated outputs of 60W, 120W, 240W, 350W to 500W6 zone speaker outputs of 100V.4-16 Ohms output for low impedance speaker connection.Six zone speaker outputs with on/off button and zone statusThree microphone inputs, two aux inputs and one line output.Mic1(6.3mm phone jack front panel) and Mic/Line input 2-3(6.3mm phone jack rear panel).Aux 1-2 inputs on rear panel by RCA.Mic1 mute with highest priorityInput and with mute level controlVolume control for Mic1-3, AuxAC power and output level meters.Overload, short circuit and high temp protectionAC 230V operation system and AC115
