Product Details:
|
| Weight: | 3.2kg | Color: | Black |
|---|---|---|---|
| Dimensions: | 483(W)×256(D)×44(H)mm | S/N Ratio: | ≥90dB |
| Network Speed: | 10/100Mbps | ||
| High Light: | lightweight IP Network Audio Encoder,network audio encoder ICMP,IP Network Audio Encoder UDP |
||
Product performance description
The IP public address system network audio Encoder is the main equipment of the IP network PA system. It is built-in Encoder which can Encode the analog audio signal into digital and transfer on network.
The IP public address (PA) system key equipment to set up the IP PA sound system, it is convenient to set up sound over network system as one IP Encoder, With this Encoder can easy connect the analog microphone or local DVD or FM into the network.
Support to encode analog signal to transfer on IP network .
Build in SD card player and can transfer the audio over internet.
It is high capacity but cost-effective multiple room network sound system.
The system could be set up over existing network, non dedicated network is needed.
System capacity of more than 500 adapters online simultaneously.
Support LAN/WAN and Internet network.
Network data delay of less than 10 milliseconds.
Program controllable power supply of AC 230V or 110V.
| Model | IP-900EC |
| Description | IP Network Audio Encoder |
| Power Supply | AC220V or 110V, 50-60Hz |
| Power Consumption | 5W |
| Network Protocol | TCP, UDP, ARP, ICMP, IGMP |
| Network Speed | 10/100Mbps |
| Audio Sampling | 8KHz-48KHz, 16 bits |
| Transmission Rate | 8Kbps to 320Kbps |
| S/N Ratio | ≥90dB |
| Frequency Response | 20Hz-20KHz |
| Data Delay | <20 milliseconds |
| Connector | One RJ45 port for LAN, one aux in, one microphone input, SD port |
| Dimensions | 483(W)×256(D)×44(H)mm |
| Weight | 2.5kg |
Guangzhou FTD Audio Limited is a leading manufacturer of Public Address System and Conference System in China, We are focus on R&D and our Professional R&D team already 15 years' experience on Audio field. FTD audio will offer the professional products and service to each of partner and do a win win business with our partners!
Our Services & Strength
1.One year warranty after sales. if any problem happened under warranty , you can return to us and fix it.
2.Accept OEM and ODM order for our customers.
3. Stable quality with good quality control, quality is our life.
4. 7*24 hours quick response for technology support.
5. Various PA system product for one shop purchase.
6. System solution designed can be offered base on requirement.
7. Reasonable price for a win win business .
